Dual output, intelligent load management; And off grid reverse control integrated machine, supporting photovoltaic, mains, and battery access.
The input voltage range of MPPT is 60-450V; 4.3-inch touch screen with RGB color bar status display
Built in Wi Fi monitoring module (Android/iOS App); BMS communication interface (RS485, CAN, RS232)
Dust proof kit design; The maximum photovoltaic input current is 27A; Intelligent charger design with balancing function to extend battery life
Dual output intelligent load
IP21 protection class
Component level MPPT increases power generation
Plug and play for easy operation and maintenance
High component-level shutdown safety
wifi communication neutral APP
Technical parameter
Product model
VMIV 4KW
Rated power
4000VA/4000W
Rated voltage
320V
working temperature
- 10°C to 50°C
size
470 * 305 * 125mm
Net weight
9
Product model
VMIV 6KW
Rated power
6000VA/6000W
Rated voltage
360V
working temperature
- 10°C to 50°C
size
470 * 305 * 125mm
Net weight
10
